APRILIA MXV 450 - Drive Chain

•
Undo and remove the screw (1).
•
Release the spring (2).
•
Remove the rear brake pedal (3).
•
Unscrew and remove the swingarm pin
fixing nut.
•
Remove the swingarm pin.
Drive chain
This vehicle is equipped with a chain without O-rings and with master link.
EXCESSIVE CHAIN SLACKENING MAY CAUSE IT TO COME OFF THE PINION OR THE CROWN,
WHICH IN TURN COULD CAUSE AN ACCIDENT OR SERIOUSLY DAMAGE THE VEHICLE.
CHECK THE CHAIN SLACK ON A REGULAR BASIS AND ADJUST IT AS NECESSARY. TO
CHANGE THE CHAIN TAKE YOUR VEHICLE TO AN Official aprilia Dealer, WHO WILL PROVIDE
ACCURATE, PROMPT SERVICE.
CAUTION
MXV 450 Chassis
CHAS - 193
