APRILIA MXV 450 - Adjustable Parameters

Adjustable parameters screen page
ADJUSTABLE PARAMETERS
This screen page is used to adjust some control unit parameters.
Throttle self-learning, min. position / Throttle
self-learning, max. position
The throttle position self-learning must be carried
out either with the throttle grip fully untwisted (idle)
or with the throttle grip fully twisted (fully open).
Advance correction / Injection time correction
The ignition advance can be modified all along the
engine operating range by 5° maximum, more or
less.
The injection time can be modified all along the
engine operating range by 5% maximum, more or
less, with respect to the basic map value.
The standard value of this parameter is 1.00.
The values that can be set range from 0.00 (cor-
responding to -5%) to 1.99 (corresponding to -5%).
Wheel diameter / Wheel signals
To obtain a correct indication of the vehicle speed,
the listed parameters can be set.
REMARK - In case the ECU has been taken from
the spare parts warehouse, the following opera-
tions/checks will be necessary:
•
Throttle self-learning operation (min. +
max. position)
•
Entering the vehicle mapping (includ-
ing correct wheel diameter setting and
qty. of screws per diameter)
The chassis number, the engine number and the
activation date cannot be entered any more.
ADJUSTABLE PARAMETERS SCREEN PAGE
Specification
Desc./Quantity
Throttle self-learning, min. position Used to store in the memory the reference value for throttle fully
homed at 0°:
Throttle self-learning, max. position Allows storage of reference value for throttle fully open by com-
pletely turning the throttle twistgrip open (to be done only when
the throttle valve is fully open, without throttle valve locking
screw)
Wheel diameter cm
Power supply MXV 450
P SUPP - 166
