APRILIA MXV 450 - Device Status

Specification Desc./Quantity
Throttle self-learning, min. position 45 - Reference value with throttle completely homed at 0°. This
value is stored by means of the "Throttle self-learning, min. po-
sition" procedure in the adjustable parameters screen page
Throttle self-learning, max. position 204 - Reference value with throttle fully open. This value is
stored by means of the "Throttle self-learning, max. position"
procedure in the adjustable parameters screen page
Wheel diameter 220 cm
Wheel signals 5 - Number of pulses per chain pinion turn.
Injection time correction 0.00 - 1.99 - Value to adjust injection times not falling within the
idle range: if equal to 1.00, it has not been changed yet. To
change it, go to the Adjustable parameters screen page.
advance correction -5.0°/ +5.0° - To change it, go to the Adjustable Parameters
screen page.
Stepper motor 100
Device status screen page
DEVICE STATUS
This screen page shows the status (usually ON/
OFF) of the vehicle devices or the operation con-
dition of some vehicle systems (for example, lamb-
da probe functioning status).
DEVICES STATUS SCREEN PAGE
Specification
Desc./Quantity
Mapping selection Soft/Hard
Gear in neutral yes/no/disconnected
There are only two statuses in this screen page:
•
The type of MAPPING, selected via the specific button (HARD / SOFT);
•
Gear in neutral, (NO): if there is no neutral sensor, the status above is permanently shown.
Devices activation screen page
DEVICES ACTIVATION
This screen page only shows the "error clearing"
function which deletes the errors saved in the con-
trol unit memory.
The vehicle devices cannot be activated.
MXV 450 Power supply
P SUPP - 163
