Iso screen page
ISO
This screen page shows general data regarding
the control unit, for example software type, map-
ping, control unit programming date
ISO SCREEN PAGE
Specification Desc./Quantity
Chassis number ZD4VP.. - Vehicle chassis
Engine number Engine number
Programming date 06/05/2008 - Date the ECU has been initialized in production
Mapping 24100 - Mapping code present in ECU
Operation time 1.10.5 - Engine operation time (at rpm higher than zero) in
days, hours and minutes
Engine parameter reading screen page
ENGINE PARAMETER READING
This screen page shows the parameters meas-
ured by the several sensors (engine revs, engine
temperature, etc.) or values set by the control unit
(injection time, ignition advance, etc.)
ENGINE PARAMETER READING SCREEN PAGE
Specification
Desc./Quantity
Engine rpm rpm
Atmospheric pressure 1010 mbar
Front cylinder injection time ms
Rear cylinder injection time ms
Front cylinder ignition advance °
Rear cylinder ignition advance °
Throttle % - The value at idle must be 0%. If the circuit is interrupted or
short circuited with voltage over 5 V, it takes the fixed value of
127% regardless the position of the throttle valves; if it is shor-
ted to ground, its fixed value is 0%.
Air temperature 20 °C - If the circuit is interrupted or short circuited with voltage
over 5 V, the parameter value is -30 °C (65506 on Axone); if
shorted to ground, the value is 130 °C.
Engine temperature 20 °C - If the circuit is interrupted or short circuited with voltage
over 5 V, the parameter value is -30 °C (65506 on Axone); if
shorted to ground, the value is 130 °C.
Battery voltage 12.5 V
Vehicle speed km/h
Power supply MXV 450
P SUPP - 162
