Stepper motor removal
•
Undo and remove the two screws.
•
Open the Stepper motor, being careful
with the O-ring.
Refitting the Stepper motor
•
Carry out the removal steps but in reverse order, remember to replace the O-ring with a new
one with the same characteristics.
Cylinders synchronisation
Cylinders cannot be synchronised.
Ecu mapping
The mapping type of the control unit of this vehicle
can be selected at any time via the key on the
handlebar.
You can choose between two different output
curves: one more aggressive and one more pro-
gressive one.
Using axone for injection system
This control unit requires using the "Walbro cable for Axone/Navigator". It consists of a cable (1) and a
joint (2).
MXV 450 Power supply
P SUPP - 159
