Undo and remove the three screws.
•
Remove the cover being careful not to
damage the O-ring.
See also
Removing the
cylinder head
Removing the
clutch cover
•
Slide off the chain from the gear.
•
Remove the gear and collect the cotter.
•
Working from the opposite side, re-
move the timing system shaft.
Engine MXV 450
ENG - 118
