APRILIA MXV 450 - Page 13

Name Torque in Nm
Upper clamp - handlebar fixing screw - M8 24 Nm (17.70 lbf ft)
FOOTRESTS
Name Torque in Nm
Footrest support bracket fixing screw - M12 50 Nm (36.88 lbf ft) - Loctite 243
Footrest support bracket fixing screw - M8 25 Nm (18.44 lbf ft) - Loctite 243
BODYWORK
Name Torque in Nm
Rod - mudguard front fixing screw - M6 12 Nm (8.85 lbf ft)
Rod - mudguard rear fixing screw - M6 12 Nm (8.85 lbf ft)
Mudguard - steering base fixing screw - M6 12 Nm (8.85 lbf ft)
Filter side lock upper fixing screw - M5 5 Nm (3.69 lbf ft)
Filter side lock lower fixing screw - M5 3 Nm (2.21 lbf ft)
Filter upper lock fixing screw - M5 4 Nm (2.95 lbf ft)
Air duct fixing screws - M6 12 Nm (8.85 lbf ft)
Fairing fixing screws - M6 12 Nm (8.85 lbf ft)
Front tail - frame fixing screw - M6 12 Nm (8.85 lbf ft)
Tail - mudguard - frame central fixing nut - M6 12 Nm (8.85 lbf ft)
Rear tail - frame fixing screw - M6 12 Nm (8.85 lbf ft)
Screw fixing undertail - mudguard - frame extension - M6 12 Nm (8.85 lbf ft)
Shock absorber protection fixing screw - M5 6 Nm (4.42 lbf ft)
Number plate retainer screw - M5 6 Nm (4.42 lbf ft)
TANKS AND RESERVOIRS
Name
Torque in Nm
Fuel tank - chassis fixing screw - M6 12 Nm (8.85 lbf ft)
Fuel pump fixing ring nut 20 Nm (14.75 lbf ft)
Screw fixing saddle guide bushing - M5 5 Nm (3.69 lbf ft) - Loctite 243
Screw fixing tank buffers - M5 5 Nm (3.69 lbf ft) - Loctite 243
OUTLET
Name
Torque in Nm
Screw fixing silencer to frame - M6 12 Nm (8.85 lbf ft)
Exhaust ends fixing nut - M6 12 Nm (8.85 lbf ft)
Pipes - head fixing screw - M6 12 Nm (8.85 lbf ft)
COOLING SYSTEM
Name
Torque in Nm
Radiators upper fixing screw - M6 12 Nm (8.85 lbf ft)
Lower screw fixing radiators - M5 5 Nm (3.69 lbf ft) - Loctite 243
CHASSIS
Name
Torque in Nm
Screw fixing frame - M8 25 Nm (18.44 lbf ft)
Upper chain roller fixing screw - M8 22 Nm (16.23 lbf ft)
Lower slider rear fixing screw - M5 5 Nm (3.69 lbf ft)
Lower slider front fixing screw - M5 5 Nm (3.69 lbf ft)
FRONT BRAKE
Name
Torque in Nm
Brake - handlebar fixing screw - M6 10 Nm (7.37 lbf ft)
Screw fixing front brake calliper - M8 25 Nm (18.44 lbf ft)
REAR BRAKE
Name
Torque in Nm
Rear brake pump fixing screw - M6 12 Nm (8.85 lbf ft)
Brake pedal fixing screw - M8 25 Nm (18.44 lbf ft) - Loctite 243
MXV 450 Characteristics
CHAR - 13
