APRILIA MXV 450 - Page 133

DESMODROMIC BEARING REMOVAL
•
Warm up the crankcase halves.
•
Remove the bearing with an extractor
from the inside.
REMOVING THE GEAR SECONDARY SHAFT
BEARING
•
Remove the two bearing grub screws
plus their plates.
•
Remove the oil seal working on the
crankcase external side.
•
Warm up the crankcase halves and
take out the bearing with an extractor
from the inside.
GEAR BEARINGS REMOVAL
•
Remove the three locking screws.
MXV 450 Engine
ENG - 133
