ENGINE
Name Torque in Nm
Engine oil drainage plug - M12x1.5 18 Nm (13.28 lbf ft)
Engine oil drainage plug on ignition cover - M12x1.5 18 Nm (13.28 lbf ft)
Gearbox oil drainage plug - M12x1.5 18 Nm (13.28 lbf ft)
Oil filter cover - M56x1.5 35 Nm (25.81 lbf ft) - Oil threading and O-ring
Piston fitting hole cover - M30x2 30 Nm (22.13 lbf ft)
Spark plug - M10x1.25 12 Nm (8.85 lbf ft)
Gearbox oil check screw - M6x1 9.8 Nm (7.23 lbf ft)
Oil pressure inlet conical cap - M10x1 18 Nm (13.28 lbf ft)
Water pump rotor - M7x1 12 Nm (8.85 lbf ft)
Head cover screw - M6x1 9.8 Nm (7.23 lbf ft)
Water pump cover screw - M6x1 8.0 Nm (5.90 lbf ft)
Clutch cover screw - M6x1 8.0 Nm (5.90 lbf ft) - Torque first removal 5.5 Nm (4.06 lbf ft)
Right crankcase cover screw - M6x1 9.8 Nm (7.23 lbf ft) - Torque first removal 5.5 Nm (4.06 lbf ft)
Crankcase clamping screw - M6x1 12 Nm (8.85 lbf ft)
Crankcase clamping screw - M7x1 15 Nm (11.06 lbf ft) - Pretorque 12 Nm (8.85 lbf ft)
Ignition cover screw - M6x1 9.8 Nm (7.23 lbf ft) - Torque first removal 5.5 Nm (4.05 lbf ft)
Pick-up fixing screw - M5x0.8 8 Nm (5.90 lbf ft) - Loctite 243
Stator fitting screw - M5x0.8 8 Nm (5.90 lbf ft) - Loctite 243
Screw fixing ignition cover flange - M5x0.8 8 Nm (5.9 lbf ft) - Loctite 243
Chain tensioner slider screw - M6x1 9.8 Nm (7.23 lbf ft) - Loctite 270
Timing chain tensioner fitting screw - M6x1 10 Nm (7.37 lbf ft)
Cable guide ring fixing screw - M6x1 10 Nm (7.37 lbf ft)
Flywheel nut - M14x1 108 Nm (79.66 lbf ft)
Screw fixing crankshaft bearing - M6x1 12 Nm (8.85 lbf ft) - Loctite 270
Secondary shaft bearing fixing screw - M6x1 10 Nm (7.37 lbf ft) - Loctite 270
Main shaft bearing fixing screw - M6x1 10 Nm (7.37 lbf ft) - Loctite 270
Screw fixing the gear selector drum bearing - M5x0.8 8 Nm (5.90 lbf ft) - Loctite 270
Head fitting screw (pre-torque) - M10x1.25 30 Nm (22.13 lbf ft) - Oil screws and washers
Head fixing screw - M10x1.25 55 Nm (40.56 lbf ft)
Timing system gear fixing nut - M12x1 50 Nm (36.88 lbf ft)
Timing compartment closing cover screw - M5x0.8 6 Nm (4.42 lbf ft) - Loctite 243
Main transmission pinion nut - M18x1.25 160 Nm (118.00 lbf ft)
Selector locking plate screw - M6x1 12 Nm (8.85 lbf ft) - Loctite 270
Plate screw for sprocket - M6x1 9.8 Nm (7.23 lbf ft) - Loctite 270
Spring retention plate screw - M6x1 9.8 Nm (7.23 lbf ft) - Loctite 270
Selector shaft grub screw - M10x1.25 25 Nm (18.44 lbf ft) - Loctite 270
Selector shaft grub screw - M6x1 12 Nm (8.85 lbf ft) - Loctite 270
Gear locking pawl rotation screw - M6x1 12 Nm (8.85 lbf ft) - Loctite 243
Selector pin - M18x1.25 22 Nm (16.23 lbf ft) - Loctite 270
APTC Clutch hub fixing nut - M18x1.25 80 Nm (59 lbf ft)
Clutch spring screw - M6x1 12 Nm (8.85 lbf ft)
Pressure relief valve - M14x.5 20 Nm (14.75 lbf ft)
Pressure pump fitting screw - M6x1 9.8 Nm (7.23 lbf ft)
Scavenge pump fitting screw - M6x1 9.8 Nm (7.23 lbf ft)
Head lubrication nozzle - M6x1 2.5 Nm (1.84 lbf ft)
Valve lifter lock screw - M5x0.8 9 Nm (6.64 lbf ft) - Loctite 270
Water joint plate screw - M6x1 9.8 Nm (7.23 lbf ft)
Crankshaft grub screw - M8x1.25 22 Nm (16.23 lbf ft) - Loctite 270
Inertial ring screws - M6x1 13 Nm (9.58 lbf ft) - Loctite 270
Start-up lever grub screw - M8x1.25 10 Nm (7.37 lbf ft) - Loctite 243
Screw fixing start-up shaft extension - M8x1.25 25 Nm (18.44 lbf ft) - Loctite 243
Screw fixing Stepper to Stepper body- self-threading ø5 mm
(0.20 in)
1.5 Nm (1.1 lbf ft)
Screw fixing Stepper to throttle body - 5x0.8 7 Nm (5.16 lbf ft) - Loctite 270
Clamps fixing throttle body sleeves - 4x0.6 4 Nm (2.95 lbf ft)
Screws fixing throttle body sleeves - M6x1 13 Nm (9.58 lbf ft) - Loctite 242
Camshaft gear fixing screw - M16x1 35 Nm (25.82 lbf ft)
Water Temperature Sensor 18 Nm (13.27 lbf ft)
Blow-by bleed joint - 48x1.5 20 Nm (14.75 lbf ft) - Loctite 243
APTC Screw fixing pressure plate - M5x0.8 8 Nm (5.9 lbf ft)
MXV 450 Characteristics
CHAR - 15
