Only for the left stem:
•
before removing the stem protection,
undo and remove the two screws fas-
tening the front brake pipe to the stem
protection.
•
Undo and remove the three stem pro-
tection fixing screws.
•
Remove the stem protection.
•
Support the stanchion and loosen the
screws on the upper and then the lower
plate.
MXV 450 Suspensions
SUSP - 173
