APRILIA MXV 450 - Page 70

F1 Supply input
G1 Supply input
H1 Reference voltage +5V output
J1 -
K1 -
L1 Fuel pump control output
M1 -
A2 Injection ground connection
B2 Air temperature sensor input
C2 -
D2 -
E2 Mapping selection input
F2 "Engine stop" input
G2 -
H2 Ground connection
J2 -
K2 -
L2 -
M2 -
A3 Front injector control output
B3 -
C3 Throttle position sensor input
D3 -
E3 Speed signal input
F3 -
G3 -
H3 Ground connection
J3 -
K3 -
L3 Ground connection
M3 Injection ground connection
A4 Rear injector control output
B4 Revolution sensor input (+)
C4 Revolution sensor input (-)
D4 Engine temperature sensor input
E4 -
F4 RX signal output
G4 TX signal output
Electrical system MXV 450
ELE SYS - 70
