7. If required, any previously programmed routes may be cleared by selecting the ‘Clear-all’ option. 7. If required, any previously programmed routes may be cleared by selecting the ‘Clear-all’ option.
Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆDigital In Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆDigital In
ÆContact#<nn>ÆRoutingÆControlÆClear-all ÆContact#<nn>ÆRoutingÆControlÆClear-all
8. Any input that is not used should be configured as ‘Not-Conf’.
Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆDigital In
ÆContact#<nn>ÆNot-Conf
Reference to Configuration Tool (Remote I/O Unit Digital Input)
