2. Technical Specifications
Specifications
Engine
− Model: Cat 3013
− Displacement: 1.5 liter
− Gross horsepower: 31.5 hp (23.5 kW)
− Torque: 64.39 lb-ft (87.3 Nm)
− Idle rpm: 2800 (high idle); 1175 (low idle)
− Hot water temperature sender: 217°F
(102.7°C)
− Average water /thermostat temperature: 190°F
(87.8°C)
Transmission
− Model: Cat AA10VG18 tandem (Rexroth)
Drive pumps
− Displacement: 1.098 in
3
/rev (18.0 cc/rev)
− Relief pressure: 3800 psi (26,200 kPa)
− Flow: 13 gpm (11.4 lpm) @ 2800 rpm (high
idle)
Charge pumps (2)
− Displacement: 0.33 in
3
/rev (5.4 cc/rev) X 2
− Relief pressure: Serial Number RSA001
through RSA01056, 450 to 500 psi (2620-
2758 kPa) at high idle with warm oil, Serial
Number RSA01057 and higher 340 to 380 psi
at high idle with warm oil.
− Flow:
a. 3 gpm (11.4 lpm) combined @ 1175 rpm
(low idle)
b. 7.8 gpm (29.5 lpm) combined @ 2800 rpm
(high idle)
Drive Motors
− Model: Eaton/Charlynn 4000 light series
− Displacement: 19.8 in
3
/rev (324.5 cc/rev)
− Shuttle control: 0.046-in fitting orifices allow 1
gpm per side @ idle with 130°F (54.4°C) oil
Control Handles
− Model: CAT 4TH6
Auxiliary Pump
− Model: Rexroth
− Displacement: 0.87 in
3
/rev (114.3 cc/rev)
− Flow: 10 gpm (37.8 lpm) @ 2800 rpm (high
idle)
− Relief pressure: 3000 psi (20,684 kPa)
− Cooling/filtering: Auxiliary oil is filtered and
cooled at all times. In Auxiliary mode, the oil is
filtered after the attachment to protect the ma-
chine if the attachment motor fails or contami-
nants are introduction from the quick couplers.
Loader Valve
− Model: Husko
− Relief pressure: 3000 psi (20,684 kPa)
− Pilot pressure required to move spools: 180-
220 psi (1241-1517 kPa)
Cooler
− Burst pressure: 400 psi (2757 kPa)
− Operating pressure: 250 psi (1724 kPa)
− Bypass relief pressure: 100 psi (689 kPa)
− Average oil temperature:
a. 50°F (10°C) above ambient in general ap-
plication
b. 80°F (26.6°C) above ambient in extreme
application
− Hot oil sending unit: 225°F (107.2°C)
Critical Torque Specs
− Drive Sprocket Retainer Bolt
o 85 ft-lb. w/Blue Loctite
− Transmission Mounting Bolts
o 80 ft-lb. w/Blue Loctite
− Drive Sprocket Drive Teeth Bolts
o 110 ft-lb. -Dry
− Bogie Wheel Retaining Nut
o 80 ft-lb. -Dry
