Rubber Track Loader
11. Engine Components Disassembly and Assembly
11-7
Figure 11-24 11-007
4. Connect the battery cable to the negative battery
terminal.
Bleeding the Fuel System
The tools required for muffler removal and installa-
tion are listed in Table 11-1. Use manufacturer-
recommended tools whenever possible.
Table 11-4
Required Tools
Combination Wrench
If the machine has been run out of fuel, it may be
necessary to bleed the fuel system. There are two
types of bleeding methods depending on the serial
number of your machine.
For serial numbers 001 through 1357.
Figure 11-25 11-006
1. Locate the bleed screw directly above the fuel
injectors.
2. Loosen the bleed screw two full turns
3. Turn-over the engine from the operators com-
partment until fuel is flowing from the bleed
screw without any air bubbles.
4. Tighten the bleed screw.
5. Engine should now start within 10 seconds.
For serial numbers 1358 and higher.
Figure 11-26 11-005
1. Locate the bleed screw directly above the fuel
injectors.
2. Loosen the bleed screw two full turns.
Figure 11-27 11-004
3. Pump the bulb primer with your hand until fuel
flows from the bleed screw without any air bub-
bles.
4. Tighten the bleed screw.
Connect
Negative
Cable
