Page 14 2000-1252-01 Released Rev. C
VersaPort 2200 Technical Manual
Chapter 1: Safety
Labeling
a
10
Ground The ground point label indicates the
location where a ground cable from
the Process Tool supply is attached to
the VersaPort. The ground point label
is located at the VersaPort platform
mount connector panel, and on the
Process Tool-side of the BOLTS
frame. (4001-8359-01)
11
Power The power panel contains these
indicators:
POWER: When this indicator is
lighted, power is being applied to the
Ve rs aP or t.
READY: When this indicator is
lighted, the VersaPort is ready to
accept a new command from the
Host.
POD IN PLACE: When this indicator
is lighted, a Pod has been properly
placed on the port. When it is off,
either a Pod is missing or it is
improperly seated on the port.
(4001-6930-01)
TABLE 1 List of VersaPort Labels (Continued)
No. Label Description / Location
POWER READY
POD IN
PLACE
TECHNOLOGIES
