Supported EtherNet/IP objects
Ethernet Link Object Instance Attribute (continued)
Attribute ID Access Rule Name Data Type Attribute Description
11 Get
Interface Capability STRUCT of Indication of capabilities of the interface.
Capability Bits DWORD Interface capabilities, other than speed/ duplex.
Speed/Duplex Options STRUCT of
Indicates speed/duplex pairs supported in the Interface Control
attribute.
USINT Speed/Duplex Array Count.
ARRAY of
STRUCT of
Speed/Duplex Array
UINT Interface Speed
UINT Interface Duplex Mode
Common Services
Ethernet Link Object Common Services
Service Code
Implemented for
Service Name Service Description
Class Instance
0x01 No Yes Get_Attribute_All Returns a predened listing of this objects attributes.
0x0E Yes Yes Get_Attribute_Single Returns the contents of the specied attribute.
0x4C No Yes* Set_Attribute_Single Gets then clears the specied attribute.
*The Get_and_Clear sevice is only implemented for the attributes 4 and 5.
A.2. Vendor Specic Objects
A.2.1. IO-Link Device Parameter Object (Class Code 0x83)
Class Attribute
IO-Link Device Parameter Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object
The current value assigned to this
attribute is one (01). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
2 Get Max Instance UINT
Maximum instance number of an object currently
created in this class level of the device.
The largest instance number of a
created object at this class hierarchy
level. This attribute will show one (01).
6 Get
Max ID Class
Attribute
UINT
The attribute ID number of the last class attribute
of the class denition implemented in the device.
The value of this attribute will be
seven (07).
7 Get
Max ID
Instance
Attributes
UINT
The attribute ID number of the last instance
attribute of the class denition implemented in the
device.
The value of this attribute will differ by
product variant.
Instance Attribute
Instance attributes are not supported.
