Supported EtherNet/IP objects
A.1.8. Ethernet Link Object (Class Code: 0xF6)
Class Attribute
Ethernet Link Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object.
The current value assigned to this
attribute is four (04). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
2 Get Max Instance UINT
Maximum instance number of an object currently
created in this class level of the device.
The largest instance number of a
created object at this class hierarchy
level. This attribute will show two (02).
3 Get
Number of
Instances
UINT
Number of object instances currently created at
this class level of the device.
The number of object instances at this
class hierarchy level. This attribute
will show two (02).
