9.2.3. Diagnostic value
9.2.3.1. Short-circuit diagnostic
Short-circuit Diagnostic (Global Error Code 0x01)
Description Value
Sensor Short Circuit 0x01
Actuator Warning 0x17
Actuator Short Circuit 0x18
9.2.3.2. Undervoltage diagnostic
Undervoltage Diagnostic (Global Error Code 0x02)
Description Value
Undervoltage Actuator Power Supply 0x28
No Voltage Actuator Power Supply 0x29
Undervoltage External Actuator Power Supply 0x2A
No Voltage External Actuator Power Supply 0x2B
Undervoltage Sensor Power Supply 0x32
No Voltage Sensor Power Supply 0x33
Undervoltage U1 0xD0
Undervoltage U2 0xD1
9.2.3.3. Overvoltage diagnostic
Overvoltage Diagnostic (Global Error Code 0x03)
Description Value
Overvoltage Actuator Power Supply 0x2C
Overvoltage External Actuator Power Supply 0x2D
Overvoltage Sensor Power Supply 0x34
Overvoltage U1 0xD4
Overvoltage U2 0xD5
9.2.3.4. General diagnostic
General Diagnostic (Global Error Code 0x09)
Description Value
Error 0x00
PLC Connection Of Exclusive Owner Timed Out 0x59
9.2.3.5. Buer overow diagnostic
Buffer Overflow Diagnostic (Global Error Code 0xFF)
Description Value
Overow 0xFF
