Supported EtherNet/IP objects
Common Services
Identity Object Common Services
Service Code
Implemented for
Service Name Service Description
Class Instance
0x01 No Yes Get_Attribute_All
Returns a predened listing of this objects
attributes.
0x05 No Yes Reset
Invokes the Reset service for the device. Option
0 restarts the device. Option 1 invokes a factory
reset of the device.
0x0E Yes Yes Get_Attribute_Single Returns the contents of the specied attribute.
A.1.2. Message Router Object (Class Code: 0x02)
This Object has no accessible attributes.
A.1.3. Assembly Object (Class Code: 0x04)
Class Attribute
Assembly Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object
The current value assigned to this
attribute is one (01). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
Instance Attribute
Assembly Object Instance Attribute
Attribute ID
Access
Rule
Name Data Type Attribute Description
3 Set,Get Data ARRAY of BYTE
4 Get Size UINT Number of bytes in Attribute 3
Common Services
Assembly Object Common Services
Service Code
Implemented for
Service Name Service Description
Class Instance
0x0E Yes Yes Get_Attribute_Single Returns the contents of the specied attribute.
0x10 No Yes Set_Attribute_Single Modies an attribute value.
