9.2.3.6. IO-Link master diagnostic
IO-Link Master Diagnostic (Global Error Code 0x40)
Description Value
Error 0x0000
Error Fetching Extended Events 0x97FF
Startup Parameterization Error 0x9801
Wrong Device. Inspection Level Mismatch 0x9802
Process Data Mismatch 0x9803
Short Circuit At C/Q - Pin 4 0x9804
IO-Link PHY Overtemperature 0x9805
Short Circuit L+ - Pin1 0x9806
Undervoltage L+ - Pin1 0x9807
Device Event Overow 0x9808
Backup Failed - Memory Out Of Range 2k 0x9809
Backup Inconsistency - Data Storage Index Not Availaeirble 0x980A
Backup Inconsistency - Data Storage Unspecic Error 0x980B
Backup Inconsistency - Upload Fault 0x980C
Parameter Inconsistency - Download Fault 0x980D
Port Class B Failure - Power Missing 0x980E
Short Circuit At Pin 2 0x980F
Revision Fault 0x9811
Compatibility Fault Vendor ID (IO-Link 1.0) 0x9812
Compatibility Fault Device ID (IO-Link 1.0) 0x9813
Compatibility Fault Vendor ID (IO-Link 1.1) 0x9814
Compatibility Fault Device ID (IO-Link 1.1) 0x9815
Serial Number Fault 0x9816
Generic Data Storage Fault 0x9817
Invalid Cycle Time 0xE000
Revision Fault- Incompatible Protocol Version 0xE001
Parameter Inconsistency - ISDU Batch Failed 0xE002
Device Not Available - Communication Lost 0xFF22
Invalid Backup - Data Storage Identication Mismatch 0xFF23
Invalid Backup - Data Storage Buffer Overow 0xFF24
Invalid Backup - Data Storage Parameter Access Denied 0xFF25
Event Lost - Incorrect Event Signaling 0xFF31
