7.4. Commissioning without EDS
NOTE
The byte addresses shown in the tables in Section 7.4 use 0-based addressing. The Productivity Suite
software uses 1-based addressing. So, add 1 to any address in these tables when accessing these values
in Productivity Suite.
7.4.1. Connections, parameters and properties
NOTE
Listen Only connections can only be established if there is already an established Multicast exclusive
owner connection .
7.4.2. Connection matrix
Exclusive Owner connection
Exclusive Owner Connection
Conguration assembly
Description
Input assembly Output assembly
Instance
170
Length
384
Instance Length Instance Length
E01 Digital IOs, IOL 32 bytes with status and diagnostics 101 394 111 260
Input Only connection
Input Only Connection
Conguration assembly
Description
Input assembly Output assembly
Instance
170
Length
384
Instance Length Instance Length
I01 Digital IOs, IOL 32 bytes with status and diagnostics 101 394 193 0
Listen Only connection
Listen Only Connection
Connection Names Description
Input assembly Output assembly
Instance Length Instance Length
L01 Digital IOs, IOL 32 bytes with status and diagnostics 101 394 192 0
7.4.3. Assemblies

Assembly Instance 170
Instance 170
Total size in bytes 384
General 0–1
Diagnostic 2–19
IO-Link port X0 20–43
IO-Link port X1 44–67
IO-Link port X2 68–91
IO-Link port X3 92–115
IO-Link port X4 116–139
IO-Link port X5 140–163
IO-Link port X6 164–187
table continued on next page
