Assembly Instance 170 (continued)
Instance 170
Total size in bytes 384
IO-Link port X7 188–211
Reserved 212–379
WebUI 380
Reserved 381–383
Sequence of input bytes
Assembly Instance 101
Instance 101
Total size in bytes 394
Digital input DI 0–1
DI Qualier 2–5
System status 6–9
IO-Link port X0 input data 10–41
IO-Link port X0 input status 42–49
IO-Link port X1 input data 50–81
IO-Link port X1 input status 82–89
IO-Link port X2 input data 90–121
IO-Link port X2 input status 122–129
IO-Link port X3 input data 130–161
IO-Link port X3 input status 162–169
IO-Link port X4 input data 170–201
IO-Link port X4 input status 202–209
IO-Link port X5 input data 210–241
IO-Link port X5 input status 242–249
IO-Link port X6 input data 250–281
IO-Link port X6 input status 282–289
IO-Link port X7 input data 290–321
IO-Link port X7 input status 322–329
Diagnostic buffer 330–393
Sequence of output bytes
Assembly Instance 111
Instance 111
Total size in bytes 260
Digital output 0–1
IO-Link port X0 output data 2–33
IO-Link port X1 output data 34–65
IO-Link port X2 output data 66–97
IO-Link port X3 output data 98–129
IO-Link port X4 output data 130–161
IO-Link port X5 output data 162–103
IO-Link port X6 output data 194–225
IO-Link port X7 output data 226–257
Diagnostic conrmation 258–259
