Supported EtherNet/IP objects
A.1.7. TCP/IP Interface Object (Class Code: 0xF5)
Class Attribute
TCP/IP Interface Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object
The current value assigned to this
attribute is four (04). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
2 Get Max Instance UINT
Maximum instance number of an object currently
created in this class level of the device,
The largest instance number of a
created object at this class hierarchy
level. This attribute will show one (01).
Instance Attribute
TCP/IP Interface Object Instance Attribute
Attribute ID Access Rule Name Data Type Attribute Description
1 Get Status USINT Interface status
2 Get
Conguration
Capability
USINT Interface capability ags.
3 Set, Get
Conguration
Capability
USINT Interface control ags.
4 Get Physical Link Object STRUCT of Path to physical link object.
Path size UINT Size of Path
Path Padded EPATH Logical segments identifying the physical link object.
5 Set, Get
Interface
Conguration
STRUCT of TCP/IP network interface conguration.
IP Address UDINT The device’s IP address.
Network Mask UDINT The device’s network mask.
Gateway Address UDINT Default gateway address.
Name Server UDINT Primary name server
Name Server 2 UDINT Secondary name server.
Domain Name STRING Default domain name.
6 Set, Get Host Name STRING Host name
10 Set, Get SelectAcd BOOL Activates the use of ACD.
11 Set, Get LastConictDetected STRUCT of Structure containing information related to the last conict detected.
AcdActivity USINT State of ACD activity when last conict detected.
RemoteMAC
Array of 6
USINT
MAC address of remote node from the ARP PDU in which a
conict was detected.
ArpPdu
ARRAY of 28
USINT
Copy of the raw ARP PDU in which a conict was detected.
12 n.c.
13 Get
Encapsulation
Inactivity Timeout
UINT
Number of seconds of inactivity before TCP connection or DTLS
session is closed.
Common Services
TCP/IP Interface Object Common Services
Service Code
Implemented for
Service Name Service Description
Class Instance
0x01 No Yes Get_Attribute_All
Returns a predened listing of this objects
attributes.
0x0E Yes Yes Get_Attribute_Single Returns the contents of the specied attribute.
0x10 No Yes Set_Attribute_Single Modies a single attribute.
