7.4.4. Conguration values
NOTICE
➔ To avoid unexpected behavior of the eldbus device, use only the values listed in this manual.
General parameters
General Parameters
Byte Parameters Value
Default
value
Description
0
Pin/Port Based IO Layout For
Digital Channels
IO Layout:
◼ 0 = Port Based
◼ 1 = Pin Based
0
Parameterizes the layout of the
I/O data
1 Reserved
Diagnostic parameters
Diagnostic Parameters
Byte Parameters Value
Default
value
Description
0 Global Diagnostic Report
◼ 0 = Disabled
◼ 1 = Enabled
1 Global diagnostics report
1
Under Voltage Sensor Supply
Diagnostic Message
◼ 0 = Do Not Report
◼ 1 = Report
1 Undervoltage US diagnostic report
2–3 Reserved Fixed 17500 Do not modify value
4
Under Voltage Actuator Supply
Diagnostic Message
◼ 0 = Do Not Report
◼ 1 = Report
1 Undervoltage UA diagnostic report
5–6 Reserved Fixed 17500 Do not modify value
7
No Actuator Supply Diagnostic
Message
◼ 0 = Do Not Report
◼ 1 = Report
1 Diagnostic report no UA
8
LED Indication For Suppressed
Diagnostic Messages
◼ 0 = No Led Indication
◼ 1 = Led Indication
0
LED indication for suppressed
diagnostic messages
9
Diagnostic Message
Acknowledgement
◼ 0 = Disabled
◼ 1 = Enabled
0 Conrmation of diagnostic message
10 Port X0 Diagnostic Report
◼ 0 = Report All Diagnostic Messages
◼ 1 = Report All Diagnostic Messages
Except for Wire Break
◼ 2 = Report Only Wire Break Diagnostic
Messages
0 Port X0 Diagnostic Report
11 Port X1 Diagnostic Report 0 Port X1 Diagnostic Report
12 Port X2 Diagnostic Report 0 Port X2 Diagnostic Report
13 Port X3 Diagnostic Report 0 Port X3 Diagnostic Report
14 Port X4 Diagnostic Report 0 Port X4 Diagnostic Report
15 Port X5 Diagnostic Report 0 Port X5 Diagnostic Report
16 Port X6 Diagnostic Report 0 Port X6 Diagnostic Report
17 Port X7 Diagnostic Report 0 Port X7 Diagnostic Report
