Supported EtherNet/IP objects
A.1.4. Connection Manager Object (Class Code: 0x06)
Class Attribute
Ethernet Link Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object
The current value assigned to this
attribute is one (01). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
2 Get Max Instance UINT
Maximum instance number of an object currently
created in this class level of the device.
The largest instance number of a
created object at this class hierarchy
level. This attribute will show one (01).
Instance Attribute
There are no Instance Attributes implemented for this object.
Common Services
Ethernet Link Object Common Services
Service Code
Implemented for
Service Name Service Description
Class Instance
0x0E Yes No Get_Attribute_Single Returns the contents of the specied attribute.
A.1.5. Device Level Ring (DLR) Object (Class Code: 0x47)
Class Attribute
Device Level Ring Object Class Attribute
Attribute
ID
Access
Rule
Name
Data
Type
Attribute Description Semantics of Value
1 Get Revision UINT Revision of this object
The current value assigned to this
attribute is three (03). If updates that
require an increase in this value are
made, then the value of this attribute
increases by 1.
Instance Attribute
Device Level Ring Object Instance Attribute
Attribute ID
Access
Rule
Name Data Type Attribute Description
1 Get
Network
Topology
USINT Current network topology mode
2 Get
Network
State
USINT Current status of network
10 Get
Active
Supervisor
Address
STRUCT of: IP and/or MAC address of the active ring supervisor
UDINT Supervisor IP Address
ARRAY of 6 USINTs Supervisor MAC Address
12 Get
Capability
Flags
USINT Describes the DLR capabilities of the device
