SIOL-EI8B-USER-M
15
Technical Data Powered by
Version 1, May 2022
Input (DI)
Sensor power supply
Per Port ≤60°C [140°F] (see Derating) ≤1A load Automatic start
Total current Sensor supply
≤40°C [104°F] (see Derating) ≤10A
Filter time
0–15 ms + tcycle, adjustable
Delay time for signal change
2–5 ms
Input characteristic
EN 61131-2 Type 1 + Type 3

MOSFET with current measurement
Connector
M12, 5-pin, A-coded
Conductor cross-section
#18 AWG
Conductor length
≤30m [98ft]
Total current
Per port ≤2A
Output (DO)

Per Port ≤60°C [140°F] (see Derating) ≤1A
Total current outputs
≤40°C [104°F] (see Derating) ≤10A
Frequency
≤50Hz
Short-circuit protection actuator
MOSFET with current measurement
Connector
M12, 5-pin, A-coded
Conductor cross-section
#18 AWG
Conductor length
≤30m [98ft]
Total current
Per port ≤2A
