260-668080-001 Rev 002 March 2013 65
Eclipse Edge User Manual
Static Routing for Example Network:
Dynamic Routing for Example Network: Select OSPF or RIP.
Portal PC TCP/IP Configuration: Use DHCP, or enter compatible TCP/IP
settings for the Ethernet LAN connection:
• IP Address 192.168.1.3
• Subnet Mask 255.255.255.0
• Default Gateway 192.168.1.1
Configuring Trap Destinations
The Trap Destinations screen supports identification of a network management
server to which traps can be sent from Eclipse via its network management network.
Two modes are supported, ProVision or Third Party:
• ProVision Mode sends a common trap for all alarms, alerting ProVision to break
its polling cycle and go straight to the alarmed Eclipse.
• Third Party Mode sends traps specific to each alarm, providing a description of the
event and it severity.
Figure shows an example Trap Destinations screen. The example shows a
destination configured for a third-party server, and a new (unconfigured) destination
added.
IDU Destination Subnet Mask Interface Next Hop
IDU1 192.168.2.0 255.255.255.0 Link NMS 0.0.0.0
192.168.3.0 255.255.255.0 Link NMS 0.0.0.0
192.168.4.0 255.255.255.0 Link NMS 0.0.0.0
192.168.5.0 255.255.255.0 Link NMS 0.0.0.0
IDU2 192.168.3.0 255.255.255.0 Ethernet 192.168.2.3
192.168.4.0 255.255.255.0 Ethernet 192.168.2.2
192.168.5.0 255.255.255.0 Ethernet 192.168.2.2
Default gateway enabled on Link NMS 0.0.0.0
IDU3 192.168.4.0 255.255.255.0 Link NMS 0.0.0.0
192.168.5.0 255.255.255.0 Link NMS 0.0.0.0
Default gateway enabled on Ethernet port 192.168.2.1
IDU4 192.168.3.0 255.255.255.0 Link NMS 0.0.0.0
Default gateway enabled on Ethernet port 192.168.2.1
IDU5 Default gateway enabled on Link NMS 0.0.0.0
IDU6 192.168.5.0 255.255.255.0 Ethernet 192.168.4.2
Default gateway enabled on Link NMS 0.0.0.0
IDU7 192.168.5.0 255.255.255.0 Link NMS 0.0.0.0
Default gateway enabled on Ethernet port 192.168.4.1
IDU8 Default gateway enabled on Link NMS 0.0.0.0
