Aviat Networks ECLIPSE EDGE User Manual

28 Aviat Networks
Chapter 5. Eclipse Edge Commissioning and Troubleshooting
Informational Events for Edge
This section introduces informational events and provides links to the descriptions
for each informational event.
Procedure for Viewing Edge Events
Informational event descriptions are listed in hierarchical format where each event
is in italics.
•Click on an informational event to view its description.
• If you are viewing within Edge Online Help, you can return to this page by clicking
the left arrow at the top of the page.
• If you are viewing within an online pdf copy of the Edge User Manual, you can
return to this page by clicking the ‘previous page arrowhead’ in the toolbar
(ensure ‘view page navigation’ is selected in the toolbar options).
• If you are using a print copy of the Edge User Manual, refer to Appendix B. .
NOTE:
Several informational events are common to more than one device.
Within Appendix B. they are only shown once and in alphabetical
order.
Refer to Edge IDU Informational Events.
Performance View current G.826 link data, plus RSL,
detected forward power, current BER,
remote fade margin, ODU temperature, and
dc power to the ODU.
Particularly useful for
cross-checking alarm events,
when there is a need to confirm
if the reported event is
affecting the path, or not.
System
Controls
Provides menus to view and set link, trib, and
AUX diagnostics.
Use to:
• Apply a digital loopback
• Apply trib loopbacks
•Apply BER tests
• Apply AIS on tribs
• View online status for
protected links
• Force protection switching
• Apply protection locks
•Apply a Tx mute
Parts Provides access to serial numbers, part
numbers, and time-in-service data.
Screen Function Tips
