260-668080-001 Rev 002 March 2013 1
AppendixA.IDU Connector and
Cable Data
This appendix provides information on:
• IDU Tributary Connectors and Cables
• NMS Connectors and Cables
Eclipse Edge tributary and NMS cables are not to be routed
with any AC mains power lines. They are also to be kept away
from any power lines which cross them.
For safety reasons tributary and NMS cables should not be
connected to outside plant.
Use approved surge suppression equipment when
connecting to un-protected external inputs and outputs.
IDU Tributary Connectors and Cables
Connector and cable data is provided for:
•E1 Trib Module
•DAC ES Module
E1 Trib Module
Refer to:
• IDU RJ-45 to BNC Cable Assembly on page 2
• IDU RJ-45 to RJ-45 Straight Cable on page 3
• IDU RJ-45 to RJ-45 Crossover Cable on page 4
• IDU RJ-45 to Wire Wrap Cable Assembly on page 5
• IDU RJ-45 Connector Pin Assignments on page 6
