22 Aviat Networks
Chapter 5. Eclipse Edge Commissioning and Troubleshooting
Eclipse Edge Alarms
The following listing is a summary of Eclipse Edge alarms. Click only on
alarm-tree-ends to view alarm details. NOTE: many of these alarms also apply to
other Eclipse products.
Refer to:
• Radio on page 22
• Radio on page 22
• Tributary on page 24
• Ethernet on page 24
IDU
Hardware
Component failure
• FPGA Software Load Failure
•RAM Failure
• Flash Card Failure
• Fixed Flash Failure
•ADC Failure
•RTC Failure
• Configuration Corrupt
Power supply
•+5VDigital Supply
• -5V Digital Supply
•+3.3V Digital Supply
• +2.5V Digital Supply
• +1.8V Digital Supply
• +1.2V Digital Supply
Temperature Warning
Software
• Configuration Corrupt
• Configuration Not Supported
• Software/Hardware Incompatible
• Date and Time Not Set
Radio
IDU
IDU Software
• Configuration Not Supported
To Next Page
