260-668080-001 Rev 002 March 2013 23
Eclipse Edge User Manual
• Remote Communications Failure
Diagnostic
•Line Facing Digital Loopback
•TX Manual Lock
• RX Source Lock
Radio Link
• Traffic Path Down
Path warning
Error warning
• ESR Threshold Exceeded
• SESR Threshold Exceeded
• 10-6 BER threshold exceeded
ODU
Hardware, ODU component failure
• Synthesiser TX or RX LO Failure
• FPGA Software Load Failure
•Tuner Failure
Temperature
•IF Card Temperature
• RX or TX Module Temperature
ODU Communications Failure
Diagnostic
•TX Power Mute
Radio Link
Tx Path failure
•TX Synthesiser Not Locked
• TX Power Failure
• ODU TX Cable Unplugged
Rx path failure
• RX Synthesiser Not Locked
• Demodulator Not Locked
•Tuner Not Locked
•ODU Cable Unplugged
Rx Path Warning
• ESR Threshold Exceeded
• SESR Threshold Exceeded
• 10-6 BER threshold exceeded
