260-668080-001 Rev 002 March 2013 13
Eclipse Edge User Manual
Check the cable and its connectors.
ODU TX Cable IF Synth Not Locked
ODU TX cable IF synthesiser not locked. This is a critical alarm.
Probable Cause
Equipment malfunction.
Recommended Actions
Replace the ODU.
Additional Information
An ODU TX cable IF synthesiser failure affects all communications to the remote-end
terminal. Remote end path alarms (BER, ES, SES, ESR, and SESR) will also be on.
ODU TX Cable Unplugged
Cannot detect ODU TX cable. This is a critical alarm.
Probable Cause
Cable is disconnected or faulty.
Recommended Actions
Check the cable and its connectors.
Additional Information
This cable demodulator is locked to the signal from the ODU cable modulator, which
in turn is locked to the demodulator.
RAC RX Cable IF Synthesiser Not Locked
The RAC RX cable IF synthesiser is not locked. This is a critical alarm.
Probable Cause
Equipment malfunction.
Recommended Actions
Withdraw the RAC, pause, then reinsert.
Replace the RAC.
RAC TX Cable IF Synth Not Locked
RAC TX cable IF synthesiser not locked. This is a critical alarm.
Probable Cause
Equipment malfunction.
Recommended Actions
Replace the RAC.
ODU Communications Failure
Cannot establish communications with the ODU. This is a major alarm.
