100 Aviat Networks
Chapter4. Eclipse Edge Configuration and Diagnostics
Viewing other Portal screens does not affect the aggregation of performance
statistics.
The Stop button terminates the data aggregation, but leaves for viewing the data
collected / displayed to that point.
The Clear button clears all data.
If the terminal is powered off or reset during data capture, a warning is displayed
advising that collected data has been interrupted.
Table 4-10 describes each statistic for the DAC ES module in the IDUspe.
Table 4-10. Description of DAC ES RMON Performance Statistics
Statistic Description
In Ucast Pkts The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were not addressed to a multicast
or broadcast address at this sub-layer.
In Broadcast Pkts The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a broadcast
address at this sub-layer.
In Multicast Pkts The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a multicast
address at this sub-layer. For a MAC layer protocol, this
includes both Group and Functional addresses.
HC In Octets The total number of octets received on the interface,
including framing characters. This object is a 64-bit version
of If In Octets.
In Discards The number of inbound packets which were chosen to be
discarded even though no errors had been detected to
prevent them being deliverable to a higher-layer protocol.
One possible reason for discarding such a packet could be
to free up buffer space.
Out UCast Pkts The total number of packets that higher-level protocols
requested be transmitted, and which were not addressed to
a multicast or broadcast address at this sub-layer, including
those that were discarded or not sent.
Out Broadcast Pkts The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to a
broadcast address at this sub-layer, including those that
were discarded or not sent.
Out Multicast Pkts The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to a
multicast address at this sub-layer, including those that
were discarded or not sent. For a MAC layer protocol, this
includes both Group and Functional addresses.
HC Out Octets The total number of octets transmitted out of the interface,
including framing characters. This object is a 64-bit version
of If Out Octets.
Dot3 In Pause
Frames
Number of valid pause frames received.
