Reference
Avidyne EX500/EX600 MFD -136- 600-00078-001 Rev 05
11.5.3 Loading NavData (the Navigation Database)
Your new EX500/EX600 will be loaded with an up-to-date navigation
database. Updates to the EX500/EX600 NavData database are
available from Jeppesen Sanderson, Inc. every 28 days.
Once you have downloaded the Nav from your PC to either a Zip Disk
Dataloader or USB Flash Memory Drive, as described in the Avidyne
Data Update Guide, you will need to upload the data to your EX500/
EX600.
To load NavData to your EX500/EX600, do the following:
1) Bring your portable USB device to the EX500/EX600 at the
aircraft.
2) Ensure that the EX500/EX600 power is OFF.
3) Connect the device to the EX500/EX600:
■ If you are using a USB Flash Memory Drive, plug it into the
data port on the front of the EX500/EX600.
■ If you are using a Zip Drive Dataloader, connect one end of
the cable to the Zip Drive and the other end to the EX500/
EX600 data port. Do not insert the Zip disk into the Zip Drive
until you have turned ON the MFD (in step 4).
Ensure that the Zip Drive is supported and not dangling by
the cable. Letting the Zip Drive dangle can cause permanent
damage to the data port. It can also cause an intermittent
connection, which will result in an unsuccessful data update.
4) Turn on the EX500/EX600. If you are using a Zip Drive, insert the
Zip disk into the Zip Drive when the initial FlightMax logo screen
is displayed.
Note: If the message, “Press any Bezel Key” is displayed, the
EX500/EX600 did not detect the portable USB device. This
can be caused by:
1. The connections were not detected by the EX500/EX600.
Check all the connections and try again.
