Avidyne EX500 - Table 11.5 Map Symbols-Navaids; Table 11.6 Map Symbols-Airports

Reference
Avidyne EX500/EX600 MFD -144- 600-00078-001 Rev 05
Navigational symbols used by Map are shown in the following three
tables:
Table 11.5 Map Symbols—Navaids
Symbol Item Heading
NDB All NDBs
VOR All VORs
Intersection Terminal, Jet, and Victor airway
waypoints (intersections)
Table 11.6 Map Symbols—Airports
Surface Airport Type
Hard Soft Water
Towered
Towered
Non-Towered
Non-Towered
