Map Symbols
600-00078-001 Rev 05 -147- Avidyne EX500/EX600 MFD
Table 11.10 AIRMET and SIGMET Boundary Lines
Line Color Type Label
Bright blue Mountain AIRMET MTN
Dark yellow IFR AIRMET IFR
Orange Turbulence AIRMET TURB
Blue Icing AIRMET ICE
Dark Red SIGMET AIRMET SIG
Blue grey Convective SIGMET CSIG
