CMax Chart Views
600-00078-001 Rev 05 -59- Avidyne EX500/EX600 MFD
6.4.1 Procedure Views
For ease of use and readability, the chart is divided into sections,
which are shown individually. Press the View key to cycle through the
available views for that chart. The available views are as follows:
The key legend shows the number of the current view as well as the
total number of views available for that procedure (i.e., “1 of 4”, “2 of
4”, and so forth).
Table 6.1 Procedure Chart Views
# View Description
1 of 4 Plan Includes a flight plan overlay, if geo-referenced
(shown on Figure 6.2 on page 57.
2 of 4 Header Contains general chart information and
appropriate communication frequencies.
3 of 4 Profile Includes the profile view of the approach
procedure. Note that in Figure 6.3, this chart is
shown with the labels removed.
4 of 4 Minimums Shows the descent minimums for the approach.
