600-00078-001 Rev 05 -33- Avidyne EX500/EX600 MFD
4 Radar Page (Optional)
The radar-capable EX500/EX600 is designed to replace an existing
radar indicator. Its user interface is more intuitive, and it is integrated
with other sensors such as traffic and lightning (if installed).
For convenience, the radar control functions used most frequently are
on the left side of the Map page. This placement enables you to use
your map functions continuously and even overlay weather radar data
on your base map.
To view the largest amount of situational data, use the Map page with
your radar. You can use the dedicated Radar page to provide
occasional radar-only display and/or detailed radar control.
Turn the right outer knob to display the Radar page. This page
provides a traditional (non-overlaid) radar display as well as
comprehensive control of the radar as well as access to the complete
list of features.
Note: Actual operation of the radar function depends on the
particular make and model of the installed radar. Make sure
you are familiar with the functionality and operation of the
radar system installed on your aircraft. See the user's guide
for your radar for details.
!
Radar is intended as a severe weather avoidance tool only.
Do not use the EX500/EX600 to penetrate severe weather,
thunderstorms, cells or lines of cells.
