Map Symbols
600-00078-001 Rev 05 -145- Avidyne EX500/EX600 MFD
Note: If all the legs are shown in white, the GPS is not reporting the
active leg of the flight plan.
Table 11.7 Map Symbols—Other
Symbol Item Symbol Item
Flight Plan
(inactive leg)*
Single Low Obstacle >= 200’
AGL < 1000’ AGL
Flight Plan
(active leg)
Low Obstacles within 1NM of
each other >= 200’ AGL <
1000’ AGL
Map Orientation Single Obstacle >= 1000’ AGL
Ownship Symbol Obstacles within 1NM of each
other >= 1000’ AGL
Flight Plan,
Course Waypoints
