Dedicated Radar Page
600-00078-001 Rev 05 -37- Avidyne EX500/EX600 MFD
10) The range scale includes the following ranges:
■ Collins - 10, 25, 50, 100, and 250nm.
■ Bendix/King - 5*, 10, 20, 40, 80, 160, 240, and 320nm,
depending on radar/Type.
!
Based on recommendations made by the FAA and the radar
manufacturer, Avidyne recommends the following safety
procedures:
• At startup, if the radar is not being used in flight, ensure
that it is turned off.
• Upon landing, if the radar is being used during the flight,
switch to standby as soon as possible.
• Set the radar to test whenever it is convenient to do so in
pre-takeoff checks. No microwave radiation is emitted in
test operation. Never turn the radar on without first
checking its operation in test mode.
• Never turn the radar on while on the ramp under any
circumstances.
