Nearest Page (NRST)
Avidyne EX500/EX600 MFD -80- 600-00078-001 Rev 05
■ ID - Airport identifier of the airport.
■ BRG - Bearing to the airport.
■ NM - Distance to the airport.
■ Freq - Radio frequency to contact this airport.
■ Name - Airport common name.
2) METAR Conditions - Displays the decoded text METAR for the
selected airport when Datalink is enabled and a METAR is
available. If the METAR cannot be decoded, the raw text of the
METAR is displayed.
Note: The units for the Decoded METAR text can be selected on
the Trip page. See “Units Key” on Page 76.
3) Airport Info - Provides quick access to airport information for the
airport highlighted. Airport Info displays a page similar to Figure
8.2 on page 81.
4) TYPE - Selects between lists of up to 50 objects within a 100nm
radius, sorted by distance. Except for Airports Nearest to
Destination, all data is shown from your present position. Press
Type to toggle through the following selections:
■ PPOS APT (Airports Nearest to Present Position) -
Graphical METARs, airport identifier, bearing, distance from
the aircraft present position, frequency, and airport name.
■ DEST APT (Airports Nearest to Destination) - Graphical
METARs, airport identifier, bearing, distance from the last
flight plan waypoint, frequency, and airport name.
■ VORs - Identifier, bearing, distance, frequency and name.
■ NDBs - Identifier, bearing, distance, frequency and name.
■ Intersections - Identifier, bearing, distance, frequency and
name.
■ Obstacles - MSL (and AGL) height, bearing and distance.
