92 AX3000 Model 80WMS - User's Manual
a) Header
BEGIN_AX_SETUP V1.1
#########################################################
# TCP/IP AX3000 Platine Terminal #
# #
# Ethernet address: 00:A0:34:20:27:10 #
# Firmware: FK18.BV2.1a/TCP.FR.0826a.STD #
# 08354 #
#########################################################
#
RESET_CMOS
Note: the RESET_CMOS command allows all the set-up parameters (except the
AX3000 IP address) to be reset. This line can be deleted or set as a comment.
b) Substitution Commands
axname_encoding_string= (yes | no)
Enabling "axname_encoding_string" allows some set-up parameters to contain
'substitution commands'. This allows variables such as the terminal name and
the session number. The substitution is done when a set-up file is sent to the
terminal.
☺: this function is useful when multiple terminals are configured with the same
set-up file, but each terminal requires certain unique parameters.
Notes:
- It works only through the remote set-up function. (It's not available with
the interactive set-up).
- Some set-up parameters are not supported by this function: the terminal
name, the passwords, the pre and post-printing sequences and the
transparent mode sequences.
The substitution commands are:
- <$> is the parameter "ethernet_axname"
