Interactive Set-Up
AX3000 Model 80WMS - User's Manual 57
3.4.10 - Connecting a Touch Screen
A USB touch screen may be seen by the terminal:
- Either as a pointer device
- Or as an USB-RS232 adaptor. In this case a logical USB port is
automatically created (see Chapter 3.4.7).
In both cases, to set-up the touch screen, select the menu [Configuration]-
[Terminal]-[Screen]. For more information see Chapter 3.2.2.
3.4.11 - Listing Connected USB Devices
To list all connected USB devices (supported or not) select the menu
[Diagnostic]-[USB]. For more information see Chapter 5.1.6.
3.5 - PRINTER MANAGEMENT
3.5.1 - Setting Up the Printer Port
Two types of ports are available for peripheral devices:
- USB logical ports: a USB logical port is automatically created when a
USB printer is connected. Four USB logical ports are available (see
Chapters 3.4.6 and 3.4.7).
- Network Printers: a TCP logical port (Net1 or Net2) allows a network
printer (or a network print server) to be addressed in the same way as a
local printer.
a) Setting USB Logical Ports
When connecting a USB printer or a USB-RS232 adaptor a USB logical port is
automatically created. This logical port (menu [Configuration]-[Ports]-[USB
Logical Ports]-[UsbX]) allows the printer to be set-up.
For more information, see Chapters 3.4.6 and 3.4.7.
