Appendix
AX3000 Model 80WMS - User's Manual 99
To enter characters with an ASCII code lower than 20 hexadecimal, use a
backslash ('\') before the hexadecimal value. For instance, the 'Esc z' sequence
can be encoded by '\1Bz'.
Note: when the character string is longer than the length of the field, two
indicators are displayed at the left and at the right of the field.
A.1.4 - Special Notation
The set-up is a sequence of menus and sub-menus. Define an action by the
path followed through the set-up tree (hierarchy), using the following notation:
[item1]-[item2]-[action]
For example, to perform the above action, select item1 in the main menu, then
select item2 in the sub-menu.
A.1.5 - Exiting the set-up
To exit the set-up, select [Configuration]-[Quit].
If changes have been made while in the set-up, a dialog box appears:
- Select [Yes] to save the modifications and exit the set-up. The new
AX3000 settings will then be stored in NVRAM (non-volatile memory).
- Select [No] to abandon your changes and exit the set-up.
A.2 - NETWORK OVERVIEW
A.2.1 - Ethernet Addresses
AX3000 terminals (like other devices equipped for Ethernet networking) have a
unique hardware address which is issued by the manufacturer and cannot be
modified. This address is in the form of six hexadecimal bytes, separated by
colons:
AX3000 Ethernet address format:
00:A0:34:xx:xx:xx
