Interactive Set-Up
AX3000 Model 80WMS - User's Manual 63
The 'time-out' parameter is the maximum number of seconds allowed for the
terminal to load a new firmware/configuration. If nothing is received in this time
the terminal boots up using existing current settings.
Two methods are available for the terminal to locate the AxRM server (IP
address and TCP port):
- Static: the IP address (or the name) and the TCP port are entered
- Dynamic (only if DHCP is already used to get the terminal IP address):
the IP address and TCP port are given through the DHCP protocol (see
Chapter 2.2.3 for more information).
For more information about Auto-Configuration stages, refer to Chapter 2.2.
3.6.3 - Factory Settings
This allows, after confirmation, terminal factory settings to be reloaded. The
current configuration is lost. See Appendix A.6.1.
3.6.4 - Local Store
The AX3000 Local Store allows the following types of object to be stored:
- TSE License: sent by a TSE/RDS Microsoft server
- Printer Properties: sent by a TSE/RDS Microsoft server when printer
redirection is enabled. See Chapter 3.3.5.
- Logo: JPEG picture. (Only one logo can be stored.)
- Personal certificate: PFX, PEM and P12 types are supported.
- Root certificate (CA): PEM and CER types are supported.
The dialog box below shows an example of AX3000 Local Store:
Adding objects: "TSE License" and "Printer properties" are issued by the TSE
server. Logos and certificates can be copied from a memory stick by clicking the
To Next Page
