AX3000 Model 80WMS - User's Manual 81
b) With bootp/tftp Protocols
Select the [Upgrade]-[Firmware]-[Update from Network] menu from the
AX3000 set-up. The following box is displayed:
Firmware can be updated in one of two ways:
- tftp protocol: the operator must enter the location of the firmware file.
- bootp and tftp protocol: this is an automatic procedure. The necessary
parameters will already be available from a bootp server.
Note: AxRM can act as a bootp/tftp server
IMPORTANT: the terminal will automatically reboot to perform this operation.
5.1.3 - The Ping Command
The ping command is used to check for the presence of a live TPC/IP device.
Select the [Diagnostics]-[Ping] dialog from the AX3000 set-up, then select the
server name from the list or enter the IP address or the DNS name of the
server.
5.1.4 - Connection Management
Connection failures are often caused by incorrect settings.
