Interactive Set-Up
60 AX3000 Model 80WMS - User's Manual
The printer declaration is completed. For the redirection procedure, consult the
Chapter 3.3.5.
3.5.3 - LPD Service
The embedded LPD print server allows the terminal printer to be accessed as a
standard system printer.
An LPD printer requires two parameters:
- The AX3000’s IP address or FQDN name if DHCP/DNS is used,
- An identifier for the printer port.
a) Setting-Up the Terminal
To set the LPD service on a port, select the [Configuration]-[Ports]-[xxx]-[yyy]
dialog and enter the following parameters:
- Service: select lpd.
- Parameters: the following dialog box is displayed:
- Printer Port Name: this is the port identifier.
- NL=CR+NL Filter: set it to 'no',
- Enhanced parameters: see Appendix A.6.3,
- Pre-print String: character string sent before the print job.
- Post-print String: character string sent after the print job (for example
"\0C" is a form feed)
b) Setting-Up the MultiPoint Server
On the MultiPoint side, a printer must be added. This printer type is 'local' and
it's attached to "TCP/IP Standard" port with the LPR protocol. The two needed
parameters are the terminal IP address and the terminal printer port name.
