Interactive Set-Up
28 AX3000 Model 80WMS - User's Manual
- Orientations: possible values are 'Landscape', 'Portrait (Flipped)' and
'Portrait'. Depending on the resolution and the number of colors, these 2
last values may be not available.
- Colors: available values are 16bpp, 24bpp and 32bpp.
- Monitor Information: this dialog box gives information about the monitor
(manufacturer, recommended resolution, available resolutions…).
Note: when exiting the dialog box the graphical settings may be tested.
b) Screen Saver
Parameters are:
- Screen Saver: this function automatically either blacks out the monitor
display (after a certain time of inactivity) or allows the screen to be locked
during the AX3000 use:
- No: function disabled.
- Yes: function enabled. The display is restored when either the
keyboard is used or data is received from the server.
- Yes keyboard only: The display is only restored when the keyboard
is used.
- Display logo: a logo can be displayed during the screen saver. This is
either the logo displayed at the terminal boot-up or the logo stored in the
AX3000 Local Store. See Chapter 3.6.4.
- Energy Star Power Saver (available only if the screen saver feature is
enabled): this saves monitor power consumption.
- Password (available only if the screen saver feature is set): the lock
screen feature is only available if a password is entered. For more
information about the lock screen feature, see Chapter 4.4.2.
- Delay (minutes) (available only if the screen saver feature is set): delay
before the monitor is turned off or locked.
c) Touch Screen
"Touch screen events" are automatically remapped into "mouse events". No
additional drivers or settings are required on the server (Windows, Unix/Linux,
AS/400...).
Touch screen parameters:
- Port: serial touch screen port (Aux1, Aux2...)
To Next Page
