Input / Output 4-5MN1902

4.3 Digital I/O

The FlexDrive

provides as standard: *

H 8 general-purpose inputs on connector block X3

H 3 general-purpose outputs on connector block X3

A digital input can be used to support many typical input functions:

H Error input

H Reset input

H Stop input

H Forward limit

H Reverse limit

H Interrupts (controlled from Mint)

H Regeneration resistor (Dynamic Brake) overtemperature input

H PLC Task input conditions

H General purpose use.

Flex+Drive

only:

H Home input

H Index selection and triggering for preset move types

H DIN4 and DIN5 are fitted with Schmitt trigger devices and can be configured using Mint for

position capture of the axis or the master/auxiliary encoder positions. See section 4.3.4.

H The main axis’ fast input (assigned using the Mint keyword FASTSELECT) can also be

used as a trigger for point to point move types. See the Mint help file for details.

* Additional I/O is available on connector X12 if the option B is fitted. See MN1908 CAN &

Auxiliary I/O option for Flex+Drive

and MintDrive
