7-6 Specifications MN1902
230- 460VAC three-phase models
(Catalog number FDH4.../FPH4...)
Unit 2.5A 5A 7.5A 15A 20A 27.5A
Switching threshold
V
in
=400VAC
V
in
=460VAC
VDC
on: 794, of f: 787 on: 794, off: 764
Nominal power (10% power cycle) kW 0.94 2.9
Peak power (10% power cycle) kW 9.4 29
Maximum regeneration
switching current
A
RMS
15 40 80
Maximum load inductance ìH 100
*Note: 2.5A models (FDH4A02... and FPH4A02...) contain an internal 200Ω, 300W resistor.
5A models (FDH4A05... and FPH4A05...) contain an internal 200Ω, 300W resistor .
7.1.6 Analog input (X3)
All models Unit All models
Type Differential
Common mode voltage range VDC ±10
Common mode rejection dB 40
Input impedanc e kÙ >5
Input ADC resolution bits 14
(includes sign bit)
Equivalent resolution mV ±1 .2
Sampling interval
Software (Mint programs)
High speed command reference signal
ìs
500
125
